Features Store-and-Forward mode with wire-speed filtering and forwarding rates
Integrated address look-up engine, supporting 8K absolute MAC addresses
9K jumbo packet support
Power saving ability for Green networking
IEEE 802.1Q VLAN packet transparency support
IEEE 802.3x flow control for full duplex operation and back pressure for half duplex operation
Hardware-based 10/100BASE-TX, half/full duplex and 1000BASE-T full duplex mode, flow control and auto-negotiation
Automatic address learning and address aging
Supports CSMA/CD protocol
Hardware Features
100~240V AC, 0.22A, 50~60Hz universal power input
DIP switch for standard/VLAN/Port Trunk/flow control off mode selection
FCC, CE class A compliant
Hardware Specifications
Hardware Version 10
10/100/1000BASE-T MDI/MDIX Ports 24
DIP Switch Operation mode selection
Standard
VLAN
Port Trunk
Flow control off
Weight 1.7kg
Power Consumption/Dissipation 10.8 watts/36 BTU
Power Requirements 100~240V AC, 0.22A, 50-60Hz
Dimensions (W x D x H) 440 x 180 x 44mm, 1U height
Switching
Switch Processing Scheme Store-and-Forward
Throughput (packet per second) 35.7Mpps
Switch Fabric 48Gbps
Address Table 8K entries
Jumbo Packet Size 9K
Flow Control Back pressure for half duplex
IEEE 802.3x Pause frame for full duplex
Standards Conformance
Regulatory Compliance FCC Part 15 Class A, CE
Standards Compliance IEEE 802.3 (Ethernet)
IEEE 802.3u (Fast Ethernet)
IEEE 802.3ab (Gigabit Ethernet)
IEEE 802.3x (Full-Duplex Flow Control)
IEEE 802.3az Energy Efficient Ethernet (EEE)
Environment
Operating Operating Temperature: 0~50 degrees C
Relative Humidity: 5% to 95% (non-condensing)
Storage Temperature: -10~70 degrees C
Relative Humidity: 5% to 95% (non-condensing)
